| Certifications | |
|---|---|
| Compliance | AS60529 |
| Protection | |
| Materials | |
| IP Rating | IP68 (7 Metres) |
Need help choosing the right product?
Our team is here to help.
Nylon cable glands for use with circular unarmoured and flexible cables to secure and ensure an IP68 entry for cable into panel or enclosure.
The cable glands in this range are suitable for use in machine and equipment construction, measuring and regulation equipment, construction site installation and many other applications.
| Part Number | Range Min. | Range Max. | Size mm² | Across Flats | Shroud | Pack Units |
|---|---|---|---|---|---|---|
| SURNG12 | 4.0 | 6.0 | M12x1.25 | 15.0 | SHR-0 | 50 |
| SURNG16 | 5.0 | 10.0 | M16x1.5 | 21.8 | SHR-1 | 50 |
| SURNG20 | 10.0 | 14.0 | M20x1.5 | 26.3 | SHR-2 | 40 |
| SURNG25 | 13.0 | 18.0 | M25x1.5 | 32.0 | SHR-3 | 20 |
| SURNG32 | 18.0 | 25.0 | M32x1.5 | 41.5 | SHR-4 | 15 |
| SURNG40 | 22.0 | 32.0 | M40x1.5 | 49.2 | SHR-5 | 6 |
| SURNG50 | 30.0 | 38.0 | M50x1.5 | 59.2 | SHR-7 | 3 |
| SURNG63 | 34.0 | 44.0 | M63x1.5 | 71.2 | SHR-8 | 2 |
