| Certifications | |
|---|---|
| Compliance | |
| Protection | |
| Materials | Brass Nickle Plated |
| IP Rating | |
Need help choosing the right product?
Our team is here to help.
| Part Number | Range Min. | Range Max. | Cable Dia. | Entry Thread Dia. | Across Corners | Across Flats | Max. Protrusion | Entry Thread Length | SWA Dia. | Braid Dia. | Shroud | Pack Units | Sealing Washer | Locknut | Earth Tag |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| GSHM20A | 8.1 | 15.2 | 9.8 | M20x1.5 | 29.4 | 25.4 | 30.0 | 11.3 | 0.9 | 0.4 | SHR-1 | 20 | W20 | PLN20 | ET20 |
| GSHM20B | 14.3 | 20.3 | 14.3 | M20x1.5 | 33.1 | 28.5 | 30.0 | 11.3 | 0.9-1.25 | 0.4-0.6 | SHR-2 | 20 | W20 | PLN20 | ET20 |
| GSHM25 | 20.0 | 28.6 | 20.1 | M25x1.5 | 40.4 | 37.2 | 35.0 | 11.3 | 1.25-1.6 | 0.6-0.8 | SHR-3 | 12 | W25 | PLN25 | ET25 |
| GSHM32 | 28.0 | 35.2 | 26.2 | M32x1.5 | 48.2 | 44.4 | 42.0 | 11.3 | 1.25-1.6 | 0.6-0.8 | SHR-4 | 6 | W32 | PLN32 | ET32 |
| GSHM40 | 34.5 | 43.8 | 34.1 | M40x1.5 | 56.8 | 52.3 | 50.0 | 13.9 | 1.6-2.0 | 0.8-1.0 | SHR-5 | 6 | W40 | PLN40 | ET40 |
| GSHM50 | 43.0 | 54.7 | 43.8 | M50x1.5 | 73.9 | 68.2 | 54.0 | 13.9 | 2.0-2.5 | 1.0-1.2 | SHR-7 | 1 | W50 | PLN50 | ET50 |
| GSHM63 | 54.0 | 68.2 | 56.0 | M63x1.5 | 87.7 | 80.9 | 58.0 | 13.9 | 2.0-2.5 | 1.0-1.2 | SHR-8 | 1 | W63 | PLN63 | ET63 |
